SSCU/1 e SSCU/1/AX

Safety PLCs for AGV and collaborative robot applications, programmable as an FSoE Master for high processing power.

Processing power for the most demanding safety

Safety PLC with an extensive library of SARC-certified mathematical functions. It is also an FSoE master device, capable of communicating with other safety devices such as drives and I/O modules. Much more powerful than its previous version (SCU-1-EC), it is a safety PLC for AGV and collaborative robot applications where significant computing power is required.

Check Check

Computing power

Check Check

Designed for AGVs

Check Check

SARC library

  • Safe logic for input, output, status, and activation signals
  • Internal memory for safety parameters
  • Safety control compliant up to PLC e (EN ISO 13849-1) or SIL3 (IEC 61508)
  • Up to 16 digital inputs
  • Up to 10 digital outputs
  • 2 relay outputs
  • Up to 6 Hokuyo laser scanners
  • Simple integration of safe drives (Safe Drive Profile)

SSCU/1 | Standard configuration
SSCU/1/AX | Standard configuration + 4 inputs for directly connecting position feedback

  • Comprehensive drive monitoring set
  • Status LEDs for I/O
  • Front-mounted multifuncion button (Quit, Start, Reset)

SSCU/1 and SSCU/1/AX are open, programmable, and configurable modules for use on EtherCAT networks, via EtherCAT, via the SafePLC2 environment developed by BBH.

SSCU/1 and SSCU/1/AX are certified by

ul certificate

The updated documentation is available on the BBH website.

PLC Safety

plc safety scu-1-ec

SCU-1-EC

plc safety scu-1-ec/nm

SCU-1-EC/NM

plc safety scu-2-ec

SCU-2-EC

plc safety scu-2-ec/nm

SCU-2-EC/NM

PLC safety per applicazioni AGV e robot collaborativi scu 1 ec/x

SSCU-1

PLC safety per applicazioni AGV e robot collaborativi scu 1 ec/x

SSCU-1/AX

Master FSoE
SARC
Up to 3 SIL 3 or PL e
Fast channel
Digital inputs Up to 14 Up to 14 Up to 14 Up to 14 Up to 16 Up to 16
Digital outputs Up to 20 Up to 20 Up to 10 Up to 10
Relè outpur 2 2 2 2 2 2
PROFIsafe
Laser scanner Up to 6 Up to 6
Speed and position inputs Up to 6
