RP-1 | AS1017.004

Motion controller – equipped with CPU G2 able to control up to 32 interpolated axes driven through CANopen or EtherCAT fieldbus

The main features are:

  • Freescale Power PC MPC5200 microprocessor (400MHz)
  • Number of controlled axes:
    • up to 32 interpolated axes, driven through Ethercat or CANopen fieldbus
  • Memory:
    • 60 Mbytes compact flash memory (expandable)
    • 64 Mbytes DRAM
    • 128 Kbytes retentive ram for parameters and alarm history storage
  • Communication:
    • # 1 general purpose RS232 serial channel (Robox BCC/31, DF1)
    • # 1 general purpose RS422/485 serial channels (Robox BCC/31, DF1)
    • # 2 Ethernet channels (10/100 Mbit/s) (CoE – Can Over EtherCAT, SoE – Servodrive Over EtherCAT, EoE – Ethernet over EtherCAT, TCP/IP, UDP, TFTP, Modbus/TCP, Ethernet/IP, Robox BCC/31/TCP)
    • # 2 Canbus channels (DS301, DS401, DS402, Device Net, Robox Cnet protocols) to interface servo drives and remoted I/O’s
    • # 1 Profibus DP slave channel
    • Master bus Axioline for communication with Axioline peripherals
    • O.P.C. Server, ActiveX, .Net Library, rLibQt, rLibJava e rLibC++ available for communication in Windows environment
  • Interfaces:
    • # 8 digital, PNP, 24VDC opto-coupled inputs (3 with capture functions)
    • # 8 digital, PNP, 24VDC, opto-coupled outputs (max 0.5A per channel)
    • # 1 incremental encoder input, RS422 line driver 5VDC with dedicate homing input
  • Expansion Boards:
    • see Remote I/Os (the bus coupler AXL-F-BK-C is not necessary)
  • ROS compliant
  • Intrinsic safety watch dog relay
  • Display monitoring the CPU status
  • Remote service
  • Real-time clock calendar
  • Power supply: 24VDC, 15W
  • External measures: mm. 100x123x96; 0.5Kg
  • Vertical or horizontal mounting in 35mm DIN guide in accordance with EN60715 standard

Programmable through RDE3 Development Environment

Icon

Leaflet 214.77 KB 6 downloads

...
Icon

EU Declaration of Conformity 72.23 KB 4 downloads

...
Icon

DWG for electric CAD 180.09 KB 5 downloads

...
Icon

E498081-D1001 580.35 KB 15 downloads

...
Icon

E498081-D1004 260.14 KB 6 downloads

...
Icon

Users' manual 2.05 MB 18 downloads

...
Icon

Product overview man_15004 4.98 MB 7 downloads

...
Icon

Wiring schematics IU1017.004 1.53 MB 10 downloads

...
Icon

STEP for mechanical CAD 295.99 KB 2 downloads

...
